2015-05-25 Product news

Alfa Laval Arctigo - Optimal design made real

The new Alfa Laval Arctigo range of industrial air coolers turn innovative design into optimal solutions for a wide variety of applications.

Based on a unique modular concept, every Arctigo air cooler is custom-built according to the specific requirements of the application to deliver optimal energy efficiency, reliability and convenience.


Application expertise

With decades of broad experience and practical expertise in heat transfer, Alfa Laval is today a world-leading supplier of heat exchangers. Combining our experience with that of Helpman and Fincoil, Alfa Laval has created a unique fusion of knowledge and technology, introducing our new range of industrial air coolers – Alfa Laval Arctigo.

Arctigo air coolers are built with an application-led approach to create the optimal design for industrial applications: from freezing and cold storage in industrial premises, cooling in slaughter houses, fish and meat processing areas, to climate control in storage rooms for fresh food.


Wide and versatile range

The single discharge industrial air coolers are ideal for both cooling and freezing applications in medium to large cold rooms. They are designed to keep fresh and frozen goods at optimum conditions, with either high or low humidity content, at a temperature range of 10°C down to -40°C. The wide and deep Arctigo range is based on a modular concept with seven different coil block modules. The modules can be combined with different construction variants, fan types and several options.


Alfa Laval Arctigo at a glance:

  • Suitable for all HFC, ammonia, CO2 & brine refrigerants
  • DX and pumped system
  • Design pressures HFC DX 33 bar, NH3 pump 27 bar, CO2 33–60 bar, brine 6 bar
  • Triangular or square pitched coil
  • Fin spacing 4 up to 12 mm
  • 1 to 8 fans, fan diameters 450 up to 1000 mm
  • Hinged fan rings for easy maintenance, saving time and cost
  • Blow-through or draw-through design
  • Room temperatures +10 down to -40 °C
  • Capacity range 3 up to 250 kW
  • Air volumes 3000 up to 120000 m3/h


Configurator and customer support

To make configuration user-friendly and convenient an online selection software offers separate modules for mechanical and thermal configuration, as well as instant access to selection and pricing of optional extras. It offers a fully sortable selection output, thanks to an interface that offers multiple language options.


Alfa Laval customers receive local support worldwide from product and application specialists from 103 sales offices in 53 countries. Original spare parts are also readily available from Alfa Laval channel partners.


About Alfa Laval:

Alfa Laval is a leading global provider of specialized products and engineering solutions based on its key technologies of heat transfer, separation and fluid handling.

The company’s equipment, systems and services are dedicated to assisting customers in optimizing the performance of their processes. The solutions help them to heat, cool, separate and transport products in industries that produce food and beverages, chemicals and petrochemicals, pharmaceuticals, starch, sugar and ethanol.

Alfa Laval’s products are also used in power plants, aboard ships, in the mechanical engineering industry, in the mining industry and for wastewater treatment, as well as for comfort climate and refrigeration applications.

Alfa Laval’s worldwide organization works closely with customers in nearly 100 countries to help them stay ahead in the global arena.
